Total Cars : 139
Engine: HA6ETI3UN – 6 cylinder turbocharged intercooled diesel
Bore x Stroke: 104 x 113 mm
Displacement: 5759 cc
Maximum Output: 180 HP at 2400 RPM
Maximum Torque: 670 Nm at 1400
Emission: Euro III with mechanical in line fuel injection equipment
Fuel tank capacity: 208 litres
Clutch: Single dry plate, hydraulic, push type clutch with power assistance
Diameter: 380mm diaphragm
Total area: 1508 sq. cm
Gear Box: ZF S6-36 OD overdrive 1st gear: 6.93 | 2nd gear: 3.79 | 3rd gear: 2.36 | 4th gear: 1.51 | 5th gear: 1 | 6th gear: 0.728 | Reverse: 6.22
Propeller Shaft: Heavy-duty propeller shaft with rubberized centre joint bearing
Rear Axle: Fully floating single speed hypoid gear with RAR 4.56:1
Front Axle: Heavy-duty 5T, A48 axle, reverse Elliot, ‘I’ section
Frame: Bolted construction constant width over chassis
Front Suspension: Parabolic leaf springs with anti-roll bar arrangement for better vehicle stability and ride comfort
Shock absorber: Heavy-duty double acting telescopic type
Rear suspension: 2 stage multileaf semi-elliptical main spring with helper spring arrangement
Steering: Integral hydraulic power assisted recirculating ball and nut
Wheels & Tyres
Rim size: 19.5 x 6.75
Tyre size: 245/70R19.5
Brakes: Full air – Full air dual line with S-CAM brake with ASA
Parking brakes: Spring actuated pneumatic on rear wheels with additional exhaust brake
Cabin: Suspended hydraulic tiltable day cabin
Electrical System: 24 V
Battery: 110 Amp./Hr. – 2×12 V
Alternator: 85 Amps
Starter motor: 4.5kW 24V
Performance Data
Max. speed in top gear: 110 kmph
Max. Gradeability: 51%
Weights (kgs)
Front Axle: 2365
Rear Axle: 1616
Unladen: 3891
GVW: 12000Kg
WheelBase: 4900
Front Overhang: 1265
Rear Overhang: 2600
Overall length: 8765
Overall width: 2200
Overall Height: 2573
Min ground Clearance: 260
Turning Circle Diameter: 18.85 m
Angle of Approach: 20°
Loading span (ft.) : 22
Angle of Departure: 14°
