Features

• Turbo charged intercooled Engine With Mechanical Pump
• 180 hp ouptut for faster trips
• 6 Speed Eaton Gearbox with higher First Gear Ratio
• Optimum Tare Weight for Higher Payload
• Hydraulic Clutch Actuation for Minimum Pedal Effort
• Full Air Dual Line Brakes
• Unique Load body with Side unloading window Higher LoadSpecifications

  Engine: HA6ETI3U – 6 Cylinder Turbocharged Intercooled
  Diesel with Inline Pump

  Bore x Stroke: 104 x 113 mm

  Displacement: 5759 cc

  Maximum Output: 180 HP (135 kW) at 2400 RPM

  Maximum Torque: 660 Nm at 1500 – 1700

  Emission: Euro III

  Air filter: Fleetguard with primary & safety element

  Fuel filter: Fleetguard Fuel filter cum water separator

  Cooling type: Pump circulated, thermostat controlled pressurised cooling with De-aeration tank

  Clutch: Air boosted Hydraulically actuated single plate dry type 15″ RDC four finger clutch (Ceramic)

  Gear Box: EATON 6 Speed  Synchromesh gearbox


  Propeller Shaft:  1710 Series
  No. of shafts: 2 No

  Rear Axle: Fully floating single speed hypoid gear Twin Rear Axle – Both Driven, Meritor Axle SQR 109

  Axle capacity: 19000 kg

  Axle Ratio: 6.17:1

  Front Axle: Forged ‘I’ section reverse elliot

  Axle capacity: 6000kg

  Frame: All Steel Ladder Type Bolted

  Suspension: Non-Reactive Semi-Elliptic laminated multileaf with center bolt arrangement

  Steering: RANE Integral power assisted steering

  Drive: RHD

  Wheels & Tyres

  Rim size: 7.5HD x 20″ – 160mm offset

  Tyre size: 1000 x 20 – 16PR

  Brakes: Full air – Dual line, S Cam

  Parking brake: Spring actuated brakes on rear only



  Electrical System: 24 V

  Battery: 110 Amp 20hr – (2x12V)

  Alternator: 55 Amps

  Starter Motor: 24V Pre-Engaged

  Performance Data

  Max. speed in top gear: 74.5 kmph

  Max. Running Gradeability: 14.3*

  Max Restart Gradeability: 12.5*

  Weights (kgs)

  Front Axle (Unladen): 3308

  Rear Axle (Unladen): 3522

  Total (Curb Weight): 6830

  Body & Payload Capacity: 18170

  GVW: 25000

  Major Dimensions

  WheelBase: 3810

  Front Overhang (Vehicle): 1483

  Rear Overhang (Vehicle): 896

  Overall length (Vehicle): 6890

  Overall width: 2500

  Overall Height (Unladen) 2850

  Front Track: 1978

  Rear Track: 1816

  Min ground Clearance: 260(mm)

  Turning Circle Diameter: 16.5 m

  Angle of Approach with FBS: 22°

  Angle of Departure with FBS: 50°

  Loading span: 5090

  Cabin Type: Cargo Day cab. Tiltable, Fully trimmed

  Features

  • Factory built Cargo cab
  • Euro III engine with Inline FIP
  • Self Starter With Thermal Cut out
  • Load Body With Side Door at RH side
  • Cross-linked polymer fuel tank
  • Combination switch with double lever
  • Ignition switch mounted on Steering column with Steering lock
